DT 209 Series
DT 209 Series
CE/CB Approved Emergency Light Model DT series
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
Lamp angle adjustment: Adjust the head to fit the building structure
Emergency duration: 3 hours
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
Lamp angle adjustment: Adjust the head to fit the building structure
Emergency duration: 3 hours
| Items | Units | Parameter | |||||
| Input Voltage | V | AC110/220V | |||||
| Source Type | - | SMD LED 56PCS*0.5W (Total 28W) | |||||
| Luminous Flux | lm | 3000 | |||||
| Brightness | cd/m2 | >15 | |||||
| Beam Angle | ° | 140 | |||||
| Body Materials | - | ABS | |||||
| Life Time | Hr | 50000 | |||||
| Work Temperature | ℃ | 0~50 | |||||
| Emergency Time | Hr | 3 | |||||
| Consumption Power | W | 12 | |||||
| Battery | - | Lead-Acid 12V4.5A | |||||
| Emergency Convension Time | s | ﹤1 | |||||
| Charge time | Hr | 48 | |||||
| Net Weight/pc (with battery) | g | 2380 | |||||
| One Pieces Packing | mm | 267x284x99 | |||||
