DT 523 Series
DT 523 Series
CE/CB Approved Emergency Light Model DT series
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
Emergency duration: 6 hours
Maximum 48 hours for full recharge time
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
Emergency duration: 6 hours
Maximum 48 hours for full recharge time
| Items | Units | Parameter | ||||
| Input Voltage | V | AC100-240V | ||||
| Source Type | - | COB 5W*2 | ||||
| Luminous Flux | lm | 600 | ||||
| Brightness | cd/m2 | >15 | ||||
| Beam Angle | ° | 140 | ||||
| Body Materials | - | ABS | ||||
| Life Time | Hr | 50000 | ||||
| Work Temperature | ℃ | 0~50 | ||||
| Emergency Time | Hr | 6Hours(one lamp)3Hours(two lamps) | ||||
| Consumption Power | W | 4 | ||||
| Battery | - | Lead-Acid 6V4A | ||||
| Emergency Convension Time | s | ﹤1 | ||||
| Charge time | Hr | 48 | ||||
| Net Weight/pc (with battery) | g | 1500 | ||||
| One Pieces Packing | mm | 380*115*158 | ||||
