DT 131 Series
DT 131 Series
CE/CB Approved Emergency Light Model DT series
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
With PIR Sensor,Luminarie shutdown time 60 seconds
Emergency duration: 1.5 hours
Maximum 48 hours for full recharge time
Injection-molded plastic ABS housing
Easy installation and maintenance
Energy-saving LEDs with long operating lifespan of up to 100,000 hours
Over-charged and over-discharged battery protections
Test button to test emergency lighting set in normal operating
LED indicator to monitor battery operating
With PIR Sensor,Luminarie shutdown time 60 seconds
Emergency duration: 1.5 hours
Maximum 48 hours for full recharge time
| Items | Units | Parameter | ||||
| Input Voltage | V | AC110-240V | ||||
| Source Type | - | SMD LED 36x0.07 | ||||
| Luminous Flux | lm | 300 | ||||
| Brightness | cd/m2 | >15 | ||||
| Beam Angle | ° | 140 | ||||
| Body Materials | - | ABS | ||||
| Life Time | Hr | 50000 | ||||
| Work Temperature | ℃ | 0~50 | ||||
| Emergency Time | Hr | 1.5 | ||||
| Consumption Power | W | 4 | ||||
| Battery | - | Ni-Cd 3.6V 900mAh | ||||
| Emergency Convension Time | s | ﹤1 | ||||
| Charge time | Hr | 48 | ||||
| Net Weight/pc (with battery) | g | 345 | ||||
| One Pieces Packing | mm | 139x213x55 | ||||
